Global Commercial Alias:
MFE180-04AN-024A-4+L518+N8020, MFE180-04AN-024A-4
Product ID:
3AUA0000164711
ABB Type Designation:
MFE180-04AN-024A-4+L518+N8020
Catalog Description:
LV AC servo drive, IEC: In 13.5 A (MFE180-04AN-024A-4+L518+N8020)
Long Description:
MotiFlex e180 is a versatile servo drive with flexible Ethernet communication protocol options. It can operate with one of the selectable built-in Ethernet protocols. A free Mint programming license is provided for the drive to realize easy positioning tasks. The drive supports various feedback types, allowing for flexible motor pairing options.
Country of Origin:
China (CN)
Finland (FI)
Customs Tariff Number:
9032899099
Invoice Description:
e180 servo drive, 3P, 380 VAC, IN: 24 A, absolute encoder, with Mint
Made To Order:
No
Minimum Order Quantity:
1 piece
Order Multiple:
1 piece
Quote Only:
No
Selling Unit of Measure:
piece
Dimensions
Product Net Weight:
10 kg
Product Net Depth / Length:
233 mm
Product Net Height:
467 mm
Product Net Width:
165 mm
Package Level 1 Units:
1 carton
Technical
Number of Phases:
3
Degree of Protection:
IP20
Frequency (f):
48 … 63 Hz
Frame Size:
C
Input Voltage (Uin):
200 … 480 V
Output Current, Normal Use (In):
13.5 A
Classifications
UNSPSC:
39122003
Environmental
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
Additional Information
Product Name:
MotiFlex e180
